Important:
Because of differences in conditions (concentration, temperature, pressure etc.) and composition of chemicals / fluids the recommended colour coding green/red/blue/black are only guidlines and should not be taken as binding. For these reasons we cannot give any guarantees as to the correctness of our recommendations in individual cases.
Back

_M 225-20

Article number: 11445405 / EAN: 7611034220086Not available anymore.
M 225-20

Powerful motorised knapsack sprayer with air-cooled 2-stroke engine, closed membrane carburettor and electronic ignition. The centrifugal pump with flow rate of 9.2 l/min gives this unit a high output performance. Ideal for professional use.

(only accessories and spare parts available)

Read more

Technical data
Chemical resistanceFor use with the most plant protection products.Not suitable for formic acid, acetic acids, sodium / potassium hydroxides. In addition stainless steel units: no hydrochlonic acid, nitric acid, sulfuric acid or hydrofluoric acid, ammonia, peroxides and other corrosive media.Not suitable for mineral oil based and vegetable oils, hypochlorites, limonenes, terpenes.
ApplicationPesticide
Water
Biological agents
Plant protection
Herbicides
Form of applicationLiquid
Filling capacity (Volume, l)20
Max. working pressure (bar)11
Nozzle type
Spray patternFanjet nozzle
Nozzles materialPlastic, brass vni
Material Device/containerPlastic
Material FittingsPlastic, brass vni
Fitting connectorsscrew fitting
Stress classHeavy duty
Device typeMotorized sprayer
Special function
Nozzles data
Adjustable nozzle 1.7 mm G1/4” (Accessories)Adjustable nozzle 1.7 mm G1/4” (Accessories)Technical parametersSpray patternAdjustable nozzle (adjustable from spraying to jet)Pressure range1 – 10 barFlow rate l/minbarDroplet size depending on pressure
Pressure (bar)12345678910
Spraying
To the nozzle
Duro mist nozzle 1.5 mm, G1/4" (Accessories)Duro mist nozzle 1.5 mm, G1/4" (Accessories)Technical parametersSpray patternHollow cone nozzle (for smaller shrubs and plants)Pressure range1 – 25 barSpray angle80°Flow rate l/minDroplet size depending on pressure
Pressure (bar)12345678910
Spraying
To the nozzle
Adjustable nozzle 1.3 mm G1/4” (Accessories)Adjustable nozzle 1.3 mm G1/4” (Accessories)Technical parametersSpray patternAdjustable nozzle (adjustable from spraying to jet)Pressure range1 – 10 barFlow rate l/minbarDroplet size depending on pressure
Pressure (bar)12345678910
Spraying
To the nozzle
Duro mist nozzle 1.3 mm, G1/4" (Accessories)Duro mist nozzle 1.3 mm, G1/4Technical parametersSpray patternHollow cone nozzle (for smaller shrubs and plants)Pressure range1 – 25 barSpray angle75°Flow rate l/minDroplet size depending on pressure
Pressure (bar)12345678910
Spraying
To the nozzle
